CBI123A
10 – 14.4Vdc, 3A, Nominal current IN = Iload: 1.1 x In A ± 5%
CBI243A
22 – 28.8Vdc, 3A, Nominal current IN = Iload: 1.1 x In A ± 5%
CBI485A
115 – 227Vdc, 5A, Nominal current IN = Iload: 1.1 x In A ± 5%.
CBI2801224A
115 - 227VAC, 10A, Nominal current IN = Iload: 1.1 x In A ± 5%.
CBI126A
10 – 14.4Vdc, 6A, Nominal current IN = Iload: 1.1 x In A ± 5%.
CBI245A
22 – 28.8Vdc, 5A, Nominal current IN = Iload: 1.1 x In A ± 5%.
CBI4810A
115 – 227VAC, 10A, Nominal current IN = Iload: 1.1 x In A ± 5%.
CBI1210A
10A, Nominal current IN = Iload: 1.1 x In A ± 5%.
CBI2410A
22 – 28.8Vdc, 10A, Nominal current IN = Iload: 1.1 x In A ± 5%.
CBI1235A
10 – 14.4Vdc, 35A, Nominal current IN = Iload: 1.1 x In A ± 5%.
CBI2420A
22 – 18.8Vdc, 10A, Nominal current IN = Iload: 1.1 x In A ± 5%.
DC-UPS = Power Supply + Battery Charger + Back Up module
Double Output. Optimised power management. Thanks to the DC-UPS units, it will be possible to smart-manage available power. It will be automatically allocated between load and battery. Supplying power to the load is the first priority of the unit, thus it is not necessary to double the power, and also the power available for the battery will go to the load if the load requires so.
The All In One range “dc UPS Power Supply” is based on two strategic know-how elements
Switching technology
Adel system has a 20 year experience in design of advanced stabilized switching technology power supplies. A Power supply/battery charger unit based on this technology is much more efficient and much smaller and lighter than traditional linear technology.
Battery Care philosophy
Unlike most other state-of-the-art battery chargers, the All In One series is equipped with a micro-processor which controls the charging process and enables several monitoring functions. The firmware implements the extended Adel battery care know-how, result of many years of experience in this field
Four main features in the same unit:
- lStabilized Power Supply
- lBack UP Module
- lBattery charger
- lBattery Care
